Z10-4
Four-Passenger Turbocharged Off-Road Machine Built for Group Adventure
The Z10-4 takes the performance and capability of the Z10 platform and expands it for four passengers, delivering an uncompromising off-road experience for groups of thrill-seekers. Powered by the same 998cc turbocharged triple-cylinder engine producing 154 hp, equipped with 2.5″ FOX shocks, and finished with a futuristic 12.3-inch digital interior with wireless CarPlay, the Z10-4 combines extreme performance with premium comfort and spacious four-passenger capability.
Engine:
998cc Turbocharged 3-Cylinder
Maximum Power:
154 hp
Suspension Travel:
430mm Front / 508mm Rear
Ground Clearance:
356 mm
Torque:
145N·m
Passengers Allowed:
4
DISCOVER
Equipment
Engine
3-cylinder, 4-stroke, liquid-cooled, DOHC, 998cc turbocharged
Fuel system
EFI
Maximum power
154hp
Maximum torque
145N·m
Transmission
CVT (enhanced)
Drive system
2WD/4WD/4WD Lock
Passengers allowed
4
Ground clearance
356mm
Front suspension travel
430mm
Rear suspension travel
508mm
Shock absorber
2.5″ FOX shocks with Quick Switch Easy adjustment (Soft / Medium / Firm)
Display
12.3-inch digital dashboard with wireless CarPlay
Rearview camera
Integrated rearview camera
Exterior
SSV-inspired front grille, special front and rear doors, striking color palette
Payload capacity
400kg
Fuel capacity
45L
Brake system
Front/Rear: Hydraulic disc
Front suspension
High clearance A-arm, 430mm travel
Rear suspension
Trailing arm, 508mm travel
Rims
14-inch alloy
Tires
30×10.00 R14
Color
Lava Orange / Nebula Black
TECHNICAL SPECIFICATIONS
ENGINE
| Specification | Details |
|---|---|
| Engine Type | 3-cylinder, 4-stroke, liquid-cooled, DOHC, turbocharged |
| Displacement | 998cc |
| Maximum Power | 154hp |
| Maximum Torque | 145N·m |
| Fuel Supply | EFI |
| Transmission | CVT (enhanced) |
DIMENSIONS & WEIGHT
| Specification | Details |
|---|---|
| Length x Width x Height | 4039 × 1625 × 1740mm |
| Wheelbase | 3277mm |
| Minimum Ground Clearance | 356mm |
| Estimated Dry Weight | 977kg |
| Payload Capacity | 400kg |
| Fuel Capacity | 45L |
| Front Suspension Travel | 430mm |
| Rear Suspension Travel | 508mm |
CHASSIS
| Specification | Details |
|---|---|
| Drive | 2WD/4WD/4WD Lock |
| Brake | Front/Rear: Hydraulic disc |
| Front Suspension | High clearance A-arm, 430mm travel |
| Rear Suspension | Trailing arm, 508mm travel |
| Shock Absorber | 2.5″ FOX shocks with Quick Switch Easy adjustment |
| Rim | 14-inch alloy |
| Tire | 30×10.00 R14 |
COLORS
| Option | Details |
|---|---|
| Available Colors | Lava Orange / Nebula Black |
