UFORCE 1000
Full-Size Work UTV Built for Strength, Capacity, and Dependable Performance
The UFORCE 1000 is a full-size utility side-by-side built for riders and workers who need serious hauling, towing, and carrying capability without compromising on comfort or refinement. Powered by a proven 963cc V-Twin EFI engine with ride-by-wire throttle and electronic power steering, it delivers a smooth, capable driving experience across demanding terrain and tough work conditions. With generous interior storage, a large cargo box, and a strong list of factory standard equipment, the UFORCE 1000 is ready to work harder and go further.
Engine:
963cc V-Twin
Drive System:
2WD/4WD
Passengers Allowed:
3
Rear Cargo Capacity:
350 kg
Torque:
74N·m
DISCOVER
Equipment
Engine
V-Twin cylinder, liquid cooled, 4-stroke, SOHC, 8-valve, 963cc
Fuel system
Bosch EFI
Throttle system
Ride-by-wire
Maximum torque
74N·m
Transmission
CVT transmission P/R/N/H/L
Drive system
2WD/4WD
EPS
Electronic power steering
Passengers allowed
3
Towing capacity
Up to 1,133kg (800kg hitch rating)
Rear cargo capacity
350kg
Payload capacity
685kg
Fuel capacity
40L
Ground clearance
280mm
Cockpit storage
80.4L total across multiple compartments
Cargo hold
356L seamless injection-molded cargo hold
Display
5-inch LCD high-definition display
Winch
3,500 lb winch
Lighting
Full LED lights
Brake system
4-Wheel Hydraulic Disc
Suspension
Double A-arm independent suspension
Shock absorber
Oil with pre-load adjustment
Rims
14-inch
Tires
27-inch
Color
Twilight Blue / Nebula Black / TT Kanati / Desert Tan
TECHNICAL SPECIFICATIONS
ENGINE
| Specification | Details |
|---|---|
| Engine Type | V-Twin cylinder, liquid cooled, 4-stroke, SOHC, 8-valve |
| Displacement | 963cc |
| Maximum Torque | 74N·m |
| Fuel Supply | Bosch EFI |
| Transmission | CVT transmission P/R/N/H/L |
DIMENSIONS & WEIGHT
| Specification | Details |
|---|---|
| Length x Width x Height | 2945 x 1615 x 1850mm |
| Wheelbase | 2050mm |
| Minimum Ground Clearance | 280mm |
| Payload Capacity | 685kg |
| Fuel Capacity | 40L |
| Rear Cargo Capacity | 350kg |
| Towing Capacity | Up to 1,133kg (800kg hitch rating) |
| Cockpit Storage | 80.4L total |
| Cargo Hold | 356L |
CHASSIS
| Specification | Details |
|---|---|
| Drive | 2WD/4WD |
| Brake | 4-Wheel Hydraulic Disc |
| Suspension | Double A-arm independent suspension |
| Shock Absorber | Oil with pre-load adjustment |
| Rim | 14-inch |
| Tire | 27-inch |
COLORS
| Option | Details |
|---|---|
| Available Colors | Twilight Blue / Nebula Black / TT Kanati / Desert Tan |
