HYDROFOILER XE-1
World's First Electric Hydrofoil Bike Built for Open Water Exploration
The Manta5 HYDROFOILER XE-1 is a groundbreaking electric hydrofoil bike that combines cycling mechanics with advanced hydrofoil technology to deliver a unique and exhilarating on-water experience. Sharing technology with America’s Cup sailboats, it rises above the water’s surface and reaches speeds of up to 22 km/h with near-silent electric power. Built from aircraft-grade aluminum and carbon fiber, with a modular design for easy transport, the XE-1 is suitable for riders of all training levels across lakes, rivers, and ocean shorelines.
Engine:
Electric
Max Load:
100 kg
Charge Time:
3 hours
Top Speed:
21 km/h
Drive System:
Pedal / Motor / Combined
Weight:
31 kg
DISCOVER
Equipment
Motor type
Electric
Motor power
400W
Maximum output
800W
Pedal drive power
460W nominal
Top speed
21–22 km/h
Cruising speed
11–13 km/h
Riding time
Up to 240 min
Charge time
180 min quick charge / approx. 4 hours standard charge
Drive modes
Pedal only / Motor only / Combined pedal and motor
Frame
6061-T6 aircraft-grade aluminum with carbon fiber elements
Rear hydrofoil span
198 cm / 2 m
Front hydrofoil span
121 cm / 1.2 m
Hydrofoils
Carbon fiber
Drivetrain
Hybrid drivetrain with standard replacement elements
Buoyancy modules
Provides stability at the surface and underwater position
Battery protection
IPX8 fully submersible watertight battery compartment
Motor protection
IPX8 water resistance
Certification
Equipment certified for sea climate
Water compatibility
Suitable for fresh and salt water
Surfer weight
Up to 100 kg
Brand
Manta5
TECHNICAL SPECIFICATIONS
ENGINE
| Specification | Details |
|---|---|
| Motor Type | Electric |
| Motor Power | 400W |
| Maximum Output | 800W |
| Pedal Drive Power | 460W nominal |
| Top Speed | 21–22 km/h |
| Cruising Speed | 11–13 km/h |
| Drive Modes | Pedal only / Motor only / Combined pedal and motor |
DRIVE UNIT
| Specification | Details |
|---|---|
| Frame Material | 6061-T6 aircraft-grade aluminum with carbon fiber elements |
| Rear Hydrofoil Span | 198 cm / 2 m |
| Front Hydrofoil Span | 121 cm / 1.2 m |
| Hydrofoil Material | Carbon fiber |
| Drivetrain | Hybrid drivetrain with standard replacement elements |
| Buoyancy Modules | Stability at surface and underwater position |
ELECTRICAL & FEATURES
| Specification | Details |
|---|---|
| Battery Protection | IPX8 fully submersible watertight battery compartment |
| Motor Protection | IPX8 water resistance |
| Quick Charge Time | 180 min |
| Standard Charge Time | Approx. 4 hours |
| Riding Time | Up to 240 min |
| Certification | Equipment certified for sea climate |
| Water Compatibility | Suitable for fresh and salt water |
| Assembly | Modular design for transport and storage |
DIMENSIONS & CAPACITY
| Specification | Details |
|---|---|
| Assembled Height | 1.4 m |
| Assembled Width | 2 m |
| Assembled Length | 2.2 m |
| Main Box Dimensions | 1.5 x 0.22 x 1.05 m |
| Foil Box Dimensions | 2.04 x 0.29 x 0.1 m |
| Weight | 31 kg |
| Max Rider Weight | 100 kg |
