Four-Passenger Utility UTV Built for Power, Comfort, and Versatility

The UFORCE 800 XL is built to deliver strong performance, spacious four-passenger comfort, and practical utility in one capable package. Powered by an 800cc V-Twin engine and engineered with ride-by-wire throttle, dual power modes, and independent suspension, it is ready for demanding workdays and off-road adventures alike. With generous interior space, a large rear cargo box, and confident all-terrain capability, the UFORCE 800 XL is designed to handle more with ease.

Engine:

800cc V-Twin Engine

Ground Clearance:

280 mm

Passengers Allowed:

4

Rear Cargo Capacity:

300 kg

Maximum Power:

63 hp

DISCOVER

800CC V-TWIN PERFORMANCE

The 800cc V-Twin engine delivers strong, smooth power with ride-by-wire throttle response, effective vibration management, and dual power modes for adaptable performance in a wide range of conditions.

COMFORT FOR FOUR

A spacious cabin accommodates four passengers, with adjustable front seats, supportive rear seating, and conveniently placed cup holders and charging ports for added comfort and usability.

PRACTICAL RANGE AND UTILITY

With 280 mm of ground clearance, independent suspension, 27-inch tires, and a rear cargo box rated to 300 kg, the UFORCE 800 XL is equipped for both demanding work and off-road travel.

Equipment

Engine
V-twin, 4-stroke, liquid-cooled, 8 valves, SOHC, 800cc

Fuel system
EFI

Throttle system
Ride-by-wire

Maximum power
63.5hp @ 7000rpm

Maximum torque
69.8N·m @ 5500rpm

Power modes
Two power modes

Transmission
CVT, P-R-N-H-L

Drive system
2WD/4WD/4WD lock

Passengers allowed
4

Rear cargo capacity
300kg

Rear cargo box dimensions
1300 × 870 × 275mm

Payload capacity
620kg

Fuel capacity
40L

Ground clearance
280mm

Brake system
Hydraulic disc with parking brake

Front suspension
High clearance A-arm independent, 225mm travel

Rear suspension
Double A-arm independent, 225mm travel

Shock absorber
Front/Rear: Spring pre-load adjustable, oil damped

Front tire
27×9.00-14

Rear tire
27×11.00-14

Color
Twilight Blue / Desert Tan / TT Kanati

TECHNICAL SPECIFICATIONS

ENGINE

SpecificationDetails
Engine TypeV-twin, 4-stroke, liquid-cooled, 8 valves, SOHC
Displacement800cc
Maximum Power63.5hp @ 7000rpm
Maximum Torque69.8N·m @ 5500rpm
Fuel SupplyEFI
TransmissionCVT, P-R-N-H-L



DIMENSIONS & WEIGHT

SpecificationDetails
Length x Width x Height3730 × 1525 × 2007mm
Wheelbase2770mm
Minimum Ground Clearance280mm
Dry Weight734kg
Payload Capacity620kg
Fuel Capacity40L
Rear Cargo Capacity300kg



CHASSIS

SpecificationDetails
Drive2WD/4WD/4WD lock
BrakeHydraulic disc with parking brake
Front SuspensionHigh clearance A-arm independent, 225mm travel
Rear SuspensionDouble A-arm independent, 225mm travel
Shock AbsorberFront/Rear: Spring pre-load adjustable, oil damped
Front Tire27×9.00-14
Rear Tire27×11.00-14



COLORS

OptionDetails
Available ColorsTwilight Blue / Desert Tan / TT Kanati
