CFORCE 625 TOURING
Two-Up Touring ATV Built for Power, Comfort, and Control
The CFORCE 625 TOURING is built for riders who want to share every journey without compromising capability. Powered by an upgraded 580cc single-cylinder engine and enhanced by ride-by-wire throttle with Dual Power Modes, it delivers stronger performance, refined control, and dependable utility across a wide range of terrain. With seating designed for two, improved ride comfort, and a rugged chassis built to tow and explore, the CFORCE 625 TOURING is ready for work and adventure alike.
Engine:
580cc Single-Cylinder EFI
Tow Capacity:
500 kg
Fuel Supply:
Bosch EFI
Maximum Power:
45 hp
Throttle System:
Ride-by-Wire
Power Modes:
Dual Power Mode
DISCOVER
Equipment
Engine
Liquid-cooled four-stroke single-cylinder, 580cc
Fuel system
Bosch EFI
Throttle system
Ride-by-Wire
Maximum power
45hp @ 6500rpm
Maximum torque
51N·m @ 6000rpm
Transmission
CVT transmission H/L/N/R/P
Drive system
2WD/4WD thumb control with 4WD differential lock
Power modes
Dual Power Mode
Seating capacity
2 riders
Tow capacity
500kg
Payload capacity
240kg
Fuel capacity
18L
Turning diameter
7.25m
Ground clearance
270mm
Color
Twilight Blue / Nebula Black / TT Kanati / Velocity Grey / CM Hunter Green
Brake system
4-Wheel Hydraulic Disc
Front suspension
Independent Dual A-Arm
Rear suspension
Independent Dual A-Arm
Shock absorber
Oil shocks with preload adjustable
Rims
12-inch alloy
Tires
6-ply all-terrain tires
TECHNICAL SPECIFICATIONS
ENGINE
| Specification | Details |
|---|---|
| Engine Type | Liquid-cooled four-stroke single cylinder with EFI |
| Displacement | 580cc |
| Bore x Stroke | 91 x 89.2mm |
| Maximum Power | 45hp @ 6500rpm |
| Maximum Torque | 51N·m @ 6000rpm |
| Fuel Supply | EFI |
| Throttle System | Ride-by-Wire |
| Transmission | CVT transmission H/L/N/R/P |
| Power Modes | Dual Power Mode |
DIMENSIONS & WEIGHT
| Specification | Details |
|---|---|
| Length x Width x Height | 2235 x 1180 x 1390 mm |
| Wheelbase | 1480 mm |
| Minimum Ground Clearance | 270 mm |
| Curb Weight | 415 kg |
| Payload Capacity | 240 kg |
| Fuel Capacity | 18 L |
| Turning Diameter | 7.25 m |
| Tow Capacity | 500 kg |
CHASSIS
| Specification | Details |
|---|---|
| Drive | 2WD/4WD thumb control with 4WD differential lock |
| Brake | 4-Wheel Hydraulic Disc |
| Front Suspension | Independent Dual A-Arm |
| Rear Suspension | Independent Dual A-Arm |
| Shock Absorber | Oil shocks with preload adjustable |
| Rim | 12-inch alloy |
| Tire | 6-ply all-terrain tires |
COLORS
| Option | Details |
|---|---|
| Available Colors | Twilight Blue / Nebula Black / TT Kanati / Velocity Grey / CM Hunter Green |
